Pigging Products Ideal For Pigging System
We stand for quality, and we are proud of it.
HYPERFORE provides fluid equipment and fluid components for hygienic pigging system. Our pipeline pigging products include various components, such as cyclone separator, 3-way diverter valve, manual swinging pannel, piggable mixing proof valve, pipeline pig detector, pig speed adjustment device, pig stopper, piggable tee, etc.
Accordingly, the equipment and components are applicable to dairy, alcohol, beverage, food, pharmaceutical, homecare and household products and industries with strict requirement for hygienic level. Furthermore, the pigging products are robust,during and cost-effective, Most importantly,
HYPERFORE pipeline pigging products make the pigging system powerful and perfect. Because they can help reduce manual intervention, complete the pigging operation efficiently and smoothly, provide customers with more options to meet the requirements of different processes. In addition, they also contribute to reduce product waste, improve production efficiency and improve profits.
We make our pigging products last long so they keep their shine as a symbol of heritage and faithfulness.
HYPERORE pipeline pigging prouducts are reliable, because of the high quality and long service life. However, the cost is low in the long run.
It takes commitment to be able to provide you with top-notch service that we’re so proud of.
For all the HYPERFORE products, we provide spare parts, maintenance service and technical support.
We start with a solid foundation, do an upgrade on your existing process flow!
HYPERFORE recommend pigging products according to the actural process flow, we upgrade existing productiong process to make it efficient.
Discover your own Pigging Products Needs
We supply different kinds of pigging products for your tailored pigging solutions.
Pig Position Detector
Cyclone Separator
Piggable Equal Diameter Tee
Automatic Pig Speed Controller
Mechanical Pig Speed Controller
Piggable Swinging Bend Panel
Why cyclone separators are important pigging products ?
When the pig is going back to the pig launcher from the receiver, the material to be discharged is a mixture of gas and liquid. However, when the gas-liquid mixture is discharged from the pipeline, the mixture will splash all over the surrounding, and cause environmental pollution. So as to prevent this from happening, a cyclone separator is required. As a result, the gas will let out from its upper outlet, and the liquid will flow out from its bottom outlet, and there will not be splashing any more.
Advantages of a cyclone separator
| Part Nr. | SIZE | A | B | C | D | E |
|---|---|---|---|---|---|---|
| DGLSKBAT013A | 1-2.5″ | 405 | 25.4 | 25.4 | 12.7 | 25.4 |
| DGLSKBAT025A | 3-4″ | 400 | 38.1 | 25.4 | 25.4 | 38.1 |
| DGLSKBAD015A | DN25-65 | 405 | 15 | 15 | 15 | 25 |
| DGLSKBAD025A | DN80-100 | 400 | 25 | 25 | 25 | 40 |
The above table shows the general technical data of the cyclone separator.
DIN 11850 series
| Part Nr. | Size | A | B | C | D |
|---|---|---|---|---|---|
| DMSSFBAD025A | DN25 | 380 | 853 | Φ29*1.5 | 130 |
| DMSSFBAD040A | DN40 | 480 | 1053 | Φ41*1.5 | 190 |
| DMSSFBAD050A | DN50 | 550 | 1053 | Φ53*1.5 | 250 |
| DMSSFBAD065A | DN65 | 750 | 1250 | Φ70*1.5 | 320 |
| DMSSFBAD080A | DN80 | 800 | 1453 | Φ85*2.0 | 400 |
| DMSSFBAD100A | DN100 | 850 | 1453 | Φ104*2.0 | 500 |
ISO series
| Part Nr. | Size | A | B | C | D |
|---|---|---|---|---|---|
| DMSSFBAT025A | 1″ | 400 | 853 | Φ25.4*1.5 | 152.4 |
| DMSSFBAT032A | 1.25″ | 480 | 853 | Φ31.8*1.5 | 190.8 |
| DMSSFBAT038A | 1.5″ | 550 | 1053 | Φ38.1*1.5 | 228.6 |
| DMSSFBAT051A | 2″ | 600 | 1053 | Φ50.8*1.5 | 304.8 |
| DMSSFBAT064A | 2.5″ | 700 | 1053 | Φ63.5*2.0 | 381 |
| DMSSFBAT076A | 3″ | 850 | 1253 | Φ76.1*2.0 | 456.6 |
| DMSSFBAT089A | 3.5″ | 950 | 1453 | Φ88.9*2.0 | 533.4 |
| DMSSFBAT101A | 4″ | 920 | 1453 | Φ101.6*2.0 | 609.6 |
The above tables are to display the size of the technical parameters of the piggable manual bend swinging panel.
| Part Nr. | Size (L/min) | A | B | C |
|---|---|---|---|---|
| DPSC00CC1010 | 10-100L/min | 514 | 210 | 434 |
| DPSC00CC2020 | 20-200L/min | 514 | 210 | 434 |
| DPSC00CC4040 | 40-400L/min | 406 | 210 | 332 |
The table above is the general technical parameters of the machanical pig speed controller
Why pig detectors are necessary pigging products ?
The pig is invisible when running in the pipeline, so the pig detector is useful to help detect the position of the pig, or for pig tracking.The stainless steel bolt assembly lock the male and female parts of the clamp around the piggable pipeline, and the clamp cushion is used to prevent the clamp from loosening and slipping.
The magnetic proximity switch is fixed on the clamp male part and locked by the self-contained nut piece to prevent vibration and falling.
Features of a pig detector
| Part Nr. | Size | D*T1 | A | T2 |
|---|---|---|---|---|
| P2721AA0254 | 1″ | 25.4*1.5 | 33.5 | 3 |
| P2722AA0318 | 1.25″ | 31.8*1.5 | 38 | 3 |
| P2723AA0381 | 1.5″ | 38.1*1.5 | 48.5 | 3 |
| P2724AA0508 | 2″ | 50.8*1.5 | 60.5 | 3 |
| P2725AA0635 | 2.5″ | 63.5*2.0 | 83.5 | 4 |
| P2726AA0761 | 3″ | 76.1*2.0 | 88.5 | 4 |
| P2727AA0889 | 3.5″ | 88.9*2.0 | 103.5 | 4 |
| P2728AA1016 | 4″ | 101.6*2.0 | 127 | 4 |
The table above is about the technical parameters of the piggable equal tee.
